The detail

Se Evo is a single-ended pure-Class-A valve power amplifier built around a direct-heated output triode and zero global feedback. NAT keeps the gain structure deliberately simple, using a short signal path and custom output magnetics to preserve the character and immediacy of the triode stage.

The amplifier’s power supply uses substantial filtering and energy storage, with soft-start protection to reduce electrical stress during switch-on. High-quality internal wiring, laboratory-grade speaker terminals and selected passive components support the hand-wired construction.

Separate output taps allow the amplifier to be matched to different loudspeaker loads. The heavy modular chassis and protective valve cage provide mechanical stability and safe everyday operation.

Complete product information

Manufacturer technical data

Complete technical specification

Complete manufacturer specifications and engineering information for Se Evo.

Configuration
Single Ended Class "A"
Frequency Response
8 Hz to 75 kHz (-3 dB)
Input Sensitivity
0,775 V RMS for max. 50 W @ zero global feedback
Input Impedance
100 kohms parallel with 200pF
Power Output THD
over 50 W @ 1 kHz @ 4 ohms or 8 ohms taps (2.9% THD @ 50 W) 0.09% @ 1 W @ 1 kHz @ 8 ohms / 8 ohms tap 0.02% @ 1 W @ 1 kHz @ 8 ohms / 4 ohms tap
Power Requirement
100 to 250 VAC @ 50 to 60 Hz, 190 VA max.
Gain
28 dB (x 25)
Dimensions
11.8" (300 mm) wide x 22.6" (575 mm) deep x 11.5" (265 mm) high
Weight
approx. 64 lbs. (29 kg) unpacked / monoblock
TOTAL Weight
approx. 190 lbs. (86 kg) packed in two flight case as option
Noise
108 dB below rated output "A" weighted
Tube Complement
1 x 6N2P-EV & 1 x GM70 (2 tubes/block)
